Wire resolution 38AWG Baggage And Parcel Inspection / x ray scanners AT5030A

Place of Origin : China

Brand Name : SECUSCAN

Certification : CE, ISO

Model Number : AT5030A

MOQ : 1

Packaging Details : Wooden Packing

Delivery Time : One week when there is stock, One month when no stock.

Payment Terms : T/T, L/C, Western Union

Supply Ability : 1000 sets/month

Price : Negotiable

Tunnel size : 500mm*300mm

Penetration : 8mm steel

X-ray Leakage : <0.05 μGy/h

Penetrate resolution : Dia 0.511mm

Film Safety : Guarantee ISO1600 Film

Conveyor loading : 100 KG

Contact Now



Wire resolution 38AWG Baggage And Parcel Inspection / x ray scanners AT5030A



Applications:

  • Airports,
  • Transport terminals,
  • Buildings,
  • Factories (to find needle in clothing,  shoes,  bags),
  • Courthouses,
  • Embassies,
  • Military installations,
  • Prisons,
  • Hotels,
  • Schools ,
  • Convention centers,
  • Security checkpoints,
  • Special events location



Specifications:



Tunnel Size:

500(W)*300(H)mm

Conveyor Speed:

0.22m/s

Conveyor Max Load:

100kgs

Dose per Inspection:

<2.9 μGy/h

Resolution:

<0.101mm Metal Wire

Penetration:

8mm Steel

Film Safety:

Guarantee ISO1600 Film

X-ray Leakage:

<0.05 μGy/h (at a distance of 5cm From external housing)

Generate direct:

Upward

Generate angle:

80 degree

Anode Voltage:

80Kv

Anode power:

0.4 to 0.5mA

Cooling / Duty Cycle:

Oil Cooling /100%

X-ray Sensor:

L-Shaped Photodiode Array (mono-energetic),  12bit Deep

Monitor:

High Resolution Color,  LCD Accord,  17 inch

Image Processing:

Edge enhancement,  image strengthening,  image lightening,

 reducing darkening,  image returning,  image retrieval.

Image Grey Level:

4096

Image Max Resolution:

1024 * 1280 pixel

Image Processing:

24bit for processing real time

Image storage:

Storage 60000 pictures in real time

Zones & Zoom:

1-9 Image regions,  2, 4, 8, 16 Times Enlarge,  Whole screen

continuous observation

Operation temperature/Humidity:

0℃-45℃/20%-95%(non-condensing)

Storage Temperature/Humidity:

-20℃-60℃/20%-95%(non-condensing)

Operation Power:

220VAC(±10%)50±3Hz

Power Consumption:

1.0 KW (max),  0.3KW(working)

Noise:

<65db





Installation and trainings



      1,we can send engineers to install and maintain machines onsite;



      2,we provide some trainings free of charge.



Packing and shipping:



PackagingDetail: Carton box Size of package:1760mm(L)*840mm(W)*1400mm(H)  Gross weight:450kgs
Delivery Detail: 5~7 days after get the payment
